Karoq 4WD

Name: Front Lower Engine Mount Hybrid Bush (Large) - Fast Road/TrackProduct Notes: PFF85-833 replaces the lower half of the original bush whilst including an insert to fit into and fill the voids in the upper bush to minimise wheel hop and improve gear-shifting. This unique bush has been designed to be fitted without subframe removal and avoids associated wheel alignment costs. . Weight: 493Fitting Instructions

Name: Front Lower Engine Mount Hybrid Bush (Large) - Fast Road/TrackProduct Notes: PFF85-831P replaces the lower half of the original bush whilst including an insert to fit into and fill the voids in the upper bush to minimise wheel hop and improve gear-shifting. This unique bush has been designed to be fitted without subframe removal and avoids associated wheel alignment costs. This part is made in our Purple Shore A 80 for vehicles running increased power or that see occasional track use. Weight: 519Fitting Instructions

Name: Front Lower Engine Mount Hybrid Bush (Large) - RoadProduct Notes: PFF85-833 replaces the lower half of the original bush whilst including an insert to fit into and fill the voids in the upper bush to minimise wheel hop and improve gear-shifting. This unique bush has been designed to be fitted without subframe removal and avoids associated wheel alignment costs. . Weight: 493Fitting Instructions

Name: Front Lower Engine Mount Hybrid Bush (Large) - RoadProduct Notes: PFF85-831 replaces the lower half of the original bush whilst including an insert to fit into and fill the voids in the upper bush to minimise wheel hop and improve gear-shifting. This unique bush has been designed to be fitted without subframe removal and avoids associated wheel alignment costs. Weight: 519Fitting Instructions

Name: Front Lower Engine Mount Hybrid Bush (Large) - Track/MSport Product Notes: PFF85-833 replaces the lower half of the original bush whilst including an insert to fit into and fill the voids in the upper bush to minimise wheel hop and improve gear-shifting. This unique bush has been designed to be fitted without subframe removal and avoids associated wheel alignment costs. Weight: 493Fitting Instructions

Name: Front Lower Engine Mount Hybrid Bush (Large) - Track/MSportProduct Notes: PFF85-831 replaces the lower half of the original bush OEM part number 5Q0 198 037 / 5Q0 198 037 A and includes an insert to fit into and fill the voids in the upper bush. This unique bush has been designed to be fitted without subframe removal from the vehicle and avoids associated wheel alignment costs. Weight: 519Fitting Instructions

Name: Front Wishbone Front BushProduct Notes: Weight: 451

Name: Front Wishbone Front BushProduct Notes: For a camber adjustable bush use PFF85-501G. Weight: 451

Name: Front Wishbone Front Bush Camber AdjustableProduct Notes: This bush features a CNC machined Stainless Steel sleeve with an offset bore that can be rotated using our bespoke tooling (supplied), giving +/- 0.5 degrees of on-car camber adjustment. Weight: 550Fitting Instructions

Name: Front Wishbone Front Bush Camber AdjustableProduct Notes: This bush features a CNC machined Stainless Steel sleeve with an offset bore that can be rotated using our bespoke tooling (supplied), giving +/- 0.5 degrees of on-car camber adjustment. Weight: 550Fitting Instructions

Name: Front Wishbone Rear BushProduct Notes: Fits steel subframes and steel wishbones only. This part features an offset bore to the sleeve to match the caster offset of the OE bush. For further caster adjustment for track/motorsport applications, use PFF3-902G. Bush Size: 65mmWeight: 1059Fitting Instructions

Name: Front Wishbone Rear BushProduct Notes: Fits steel subframes and steel wishbones only. This part features an offset bore to the sleeve to match the caster offset of the OE bush. For further caster adjustment for track/motorsport applications, use PFF3-902GBLK. Bush Size: 65mmWeight: 1059Fitting Instructions

Name: Lower Engine Mount (Large) InsertProduct Notes: Weight: 240Fitting Instructions

Name: Lower Engine Mount (Large) InsertProduct Notes: Weight: 245Fitting Instructions

Name: Lower Engine Mount (Large) Insert DieselProduct Notes: Some NVH transmission should be expected when fitting this part to a Diesel vehicle. Weight: 240Fitting Instructions

Name: Lower Engine Mount (Large) Insert Track UseProduct Notes: Made in Purple 80A and suitable for higher powered cars and track cars, this part helps to further reduce engine movement over fitting the standard PFF85-832 insert. Increased NVH may be felt when fitted. Weight: 240Fitting Instructions

Name: Lower Engine Mount Insert (Large)Product Notes: Weight: 240Fitting Instructions

Name: Lower Engine Mount Insert (Large)Product Notes: Weight: 240Fitting Instructions

Name: Lower Engine Mount Insert (Large) DieselProduct Notes: Suitable for diesel models, using a softer material that helps reduce movement from the bush but transmits less noise and vibration over fitting the standard PFF85-830 insert. Weight: 240Fitting Instructions

Name: Lower Engine Mount Insert (Large) Track UseProduct Notes: Suitable for higher powered cars and track cars, using a stiffer material which helps further reduce engine movement over fitting the standard PFF85-830 insert, being a stiffer material additional noise and vibration may be felt. Weight: 240Fitting Instructions

Name: Lower Torque Mount Small BushProduct Notes: PFF3-1325 Lower Torque Mount Bushis made from our stiffestBlack 95Amaterial to provide a durable replacement for the factory rubber bush to give road or tuned vehicles a sharper throttle response and more positive gear-change without compromising ride quality and NVH. An increase in stiffness by 50% over the worn OE rubber bush helps to reduce excessive engine movement caused by the torque reaction of the engine during acceleration and deceleration, one of the biggest causes of wheel-hop on tuned FWD or front-engined vehicles. Please check which type of bracket is fitted to the vehicle before ordering. See the part numbers above and photos below for reference. Weight: 132

Name: Lower Torque Mount Small Bush Product Notes: PFF3-1326 Lower Torque Mount Bush is made from our stiffest Black 95A material to provide a durable replacement for the factory rubber bush to give road or tuned vehicles a sharper throttle response and more positive gear-change without compromising ride quality and NVH. An increase in stiffness by 50% over the worn OE rubber bush helps to reduce excessive engine movement caused by the torque reaction of the engine during acceleration and deceleration, one of the biggest causes of wheel-hop on tuned FWD or front-engined vehicles. Please check which type of bracket is fitted to the vehicle before ordering. Weight: 0

Name: Lower Torque Mount Small Bush Product Notes: PFF3-1326 Lower Torque Mount Bush is made from our stiffest Black 95A material to provide a durable replacement for the factory rubber bush to give road or tuned vehicles a sharper throttle response and more positive gear-change without compromising ride quality and NVH. An increase in stiffness by 50% over the worn OE rubber bush helps to reduce excessive engine movement caused by the torque reaction of the engine during acceleration and deceleration, one of the biggest causes of wheel-hop on tuned FWD or front-engined vehicles. Please check which type of bracket is fitted to the vehicle before ordering. Weight: 100

Name: Lower Torque Mount Small BushProduct Notes: PFF3-1325BLK Lower Torque Mount Bushis made from our stiffestBlack 95Amaterial to provide a durable replacement for the factory rubber bush to give road or tuned vehicles a sharper throttle response and more positive gear-change without compromising ride quality and NVH. An increase in stiffness by 50% over the worn OE rubber bush helps to reduce excessive engine movement caused by the torque reaction of the engine during acceleration and deceleration, one of the biggest causes of wheel-hop on tuned FWD or front-engined vehicles. Please check which type of bracket is fitted to the vehicle before ordering. See the part numbers above and photos below for reference. Weight: 132

Name: PowerAlign Wheel Mounting Guide PinProduct Notes: Available singularly to suit a specific vehicle or as a handy 4-piece workshop kit, our new PowerAlign Wheel Mounting Guide Pins are designed to allow the safer mounting and easy alignment of heavy alloy wheels on most common cars to use lug bolts. The individual pins come supplied in a reusable twist tube and the 4-piece workshop kit is supplied with a steel storage case for pride of place in your toolbox.Simply thread the appropriate pin size into one of the bolt holes on the wheel hub. The wheel can then be lifted and placed on the guide pin, and easily slid into place on the hub; keeping the bolt holes aligned for other bolts to be inserted and tightened.This reduces the awkward and back-straining process of holding the wheel in place with one hand whilst lining up and threading in the first bolt; thus, reducing the risk, hassle, and strain of mounting wheels.Proven using simulated and real-world testing, the new mounting pins usehigh-strength CNC-machined AISI 303 Stainless Steel, some 50% stronger than plated mild steel, to ensure durability and resilience in a workshop environment, and are supplied with colour-coded 3D-printedprotective sleeves for ease of identificationandanodised 2011-T6 aluminium caps to absorb knocks and prevent damage to the wheel, unlike others on the market.Please clickhereto view all sizes available and fora wider-reaching application list in the form of anew user-friendly drop-down search function. Weight: 122

Name: Rear Anti Roll Bar Bush 19.6mmProduct Notes: Bush Size: 19.6mmWeight: 137

Name: Rear Anti Roll Bar Bush 19.6mmProduct Notes: Bush Size: 19.6mmWeight: 137

Name: Rear Diff Front Mounting BushProduct Notes: This bush fits models only where the bush location in the diff casing measures 35mm tall as found on AWD MQB platform and 2015-on PQ35 platform vehicles. If in doubt, measure the height of the front casing mount before ordering. If the mount is 30mm in height or the OEM part number on your vehicle is 1K0 599 431, please use PFR85-523. Bush Size: 35mmWeight: 535Fitting Instructions

Name: Rear Diff Front Mounting Bush Product Notes: This bush fits 4 wheel drive models only where the differential casing front mount measures 35mm in width. The 35mm differential casing mount is found on AWD MQB platform and 2015-on PQ35 platform vehicles. The OEM rubber front mount must be part number 1K0 599 437 for this bush to replace. If in doubt, measure the height of the casing front mount before ordering. If the mount is 30mm in height or the OEM part number on your vehicle is 1K0 599 431 then use PFR85-523. Bush Size: 35mmWeight: 535Fitting Instructions

Name: Rear Diff Rear Mounting Bush Product Notes: This bush fits 4 wheel drive models only. Weight: 970Fitting Instructions

Name: Rear Diff Rear Mounting BushProduct Notes: Fits 4WD models only. Weight: 970Fitting Instructions

Name: Rear Lower Arm Outer Bush Product Notes: Weight: 412
