A1 Quattro (2013)

Name: Front Anti Roll Bar Bush 20mmProduct Notes: Weight: 71

Name: Front Anti Roll Bar Bush 20mmProduct Notes: Weight: 71

Name: Front Arm Rear BushProduct Notes: For the Skodia Fabia 5J, this bush only fits models with these chassis numbers: F5J 8A502 657 Onward, F5J 8B503 032 Onward, F5J 8K450 961 Onward, F5J 83172 974 Onward. Weight: 780Fitting Instructions

Name: Front Arm Rear BushProduct Notes: For the Skodia Fabia 5J, this bush only fits models with these chassis numbers: F5J 8A502 657 Onward, F5J 8B503 032 Onward, F5J 8K450 961 Onward, F5J 83172 974 Onward. Weight: 780Fitting Instructions

Name: Front Strut Top Mount BushProduct Notes: Weight: 618Fitting Instructions

Name: Front Strut Top Mount BushProduct Notes: Weight: 618Fitting Instructions

Name: Front Strut Top Mount Bush -10mmProduct Notes: This part has been designed to reduce the ride height by 10mm when fitted as it allows the strut to sit higher into the body of the top mount. It is supplied with a new top cap spacer made using our 95A durometer material, meaning no more modifying of original parts. For standard ride height top mounts, please use PFF85-430. Bush Size: -10mmWeight: 591Fitting Instructions

Name: Front Strut Top Mount Bush -10mmProduct Notes: This part has been designed to reduce the ride height by 10mm when fitted as it allows the strut to sit higher into the body of the top mount. It is supplied with a new top cap spacer made using our 95A durometer material, meaning no more modifying of original parts. For standard ride height top mounts, please use PFF85-430BLK. Bush Size: -10mmWeight: 591Fitting Instructions

Name: Front Wishbone Front Bush 30mmProduct Notes: If fitting on Audi TT MK1, S3 and A3 MK1 and Seat Leon & Cupra MK1 it fits earlier models with a 30mm diameter. It fits both the pressed and cast arms on the Leon & Cupra MK1 and A3 MK1 2WD. Please check original bush size. Later cars may use a larger 45mm bush PFF3-501. For an on-car camber adjustable version of this bush please use PFF85-201G. Bush Size: 30mmWeight: 263

Name: Front Wishbone Front Bush 30mmProduct Notes: If fitting on Audi TT MK1, S3 and A3 MK1 and Seat Leon & Cupra MK1 it fits earlier models with a 30mm diameter. It fits both the pressed and cast arms on the Leon & Cupra MK1 and A3 MK1 2WD. Please check original bush size. Later cars may use a larger 45mm bush PFF3-501. For an on-car camber adjustable version of this bush please use PFF85-201GBLK. Bush Size: 30mmWeight: 263

Name: Front Wishbone Front Bush 30mm Camber Adjustable Product Notes: PFF85-201G gives +/- 0.5 degrees of camber adjustment. If fitting on Audi TT MK1, S3 and A3 MK1 and Seat Leon & Cupra MK1 it fits earlier models with a 30mm diameter. It fits both the pressed and cast arms on the Leon & Cupra MK1 and A3 MK1 2WD. Please check original bush size. Later cars may use a larger (nonadjustable) 45mm bush PFF3-501. PFF85-201G bush features a CNC machined Stainless Steel sleeve with an offset bore that can be rotated using our bespoke tooling (supplied), giving +/- 0.5 degrees of camber adjustment. For a non-offset version of this bush please use PFF85-201.Knurled end faces prevent sleeve rotation to retain suspension geometry.PFF85-201G boosts stiffness over the original part by 15%. Bush Size: 30mmWeight: 355Fitting Instructions

Name: Front Wishbone Front Bush 30mm Camber Adjustable Product Notes: PFF85-201G gives +/- 0.5 degrees of camber adjustment. If fitting on Audi TT MK1, S3, and A3 MK1 and Seat Leon & Cupra MK1 it fits earlier models with a 30mm diameter. It fits both the pressed and cast arms on the Leon & Cupra MK1 and A3 MK1 2WD. Please check the original bush size. Later cars may use a larger (non-adjustable) 45mm bush PFF3-501. PFF85-201G bush features a CNC machined Stainless Steel sleeve with an offset bore that can be rotated using our bespoke tooling (supplied), giving +/- 0.5 degrees of on-car camber adjustment. For a non-offset version of this bush please use PFF85-201.Knurled end faces prevent sleeve rotation to retain suspension geometry.PFF85-201GBLK boosts stiffness over the original part by 15%. Bush Size: 30mmWeight: 355Fitting Instructions

Name: Lower Engine Mount Large Bush (M-Sport)Product Notes: PFF85-620BLK uses our Black 95A durometer material for heavily tuned vehicles or Motorsport use. Fitting this engine mount bush to 1.4 TDI 3 cylinders is not advisable. An increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted. Weight: 404

Name: Lower Engine Mount Large Bush (Std Petrol)Product Notes: PFF85-620 is made using our Yellow 70A durometer material and is suitable for standard petrol models or mildly tuned diesel models. For track/tuned models use PFF85-620P. Fitting this engine mount bush to 1.4 TDI 3 cylinders is not advisable. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted. Weight: 404

Name: Lower Engine Mount Large Bush (Tuned/Track)Product Notes: PFF85-620P uses our Purple 80A durometer material and is suitable for significantly tuned cars or those used on track. Fitting this engine mount bush to 1.4 TDI 3 cylinders is not advisable. A small increase in NVH, usually at idle, should be expected when stiffening the connecting mount between the engine/transmission and chassis. The harder the material used, the greater the NVH transmitted. Weight: 404

Name: PowerAlign Wheel Mounting Guide PinProduct Notes: Available singularly to suit a specific vehicle or as a handy 4-piece workshop kit, our new PowerAlign Wheel Mounting Guide Pins are designed to allow the safer mounting and easy alignment of heavy alloy wheels on most common cars to use lug bolts. The individual pins come supplied in a reusable twist tube and the 4-piece workshop kit is supplied with a steel storage case for pride of place in your toolbox.Simply thread the appropriate pin size into one of the bolt holes on the wheel hub. The wheel can then be lifted and placed on the guide pin, and easily slid into place on the hub; keeping the bolt holes aligned for other bolts to be inserted and tightened.This reduces the awkward and back-straining process of holding the wheel in place with one hand whilst lining up and threading in the first bolt; thus, reducing the risk, hassle, and strain of mounting wheels.Proven using simulated and real-world testing, the new mounting pins usehigh-strength CNC-machined AISI 303 Stainless Steel, some 50% stronger than plated mild steel, to ensure durability and resilience in a workshop environment, and are supplied with colour-coded 3D-printedprotective sleeves for ease of identificationandanodised 2011-T6 aluminium caps to absorb knocks and prevent damage to the wheel, unlike others on the market.Please clickhereto view all sizes available and fora wider-reaching application list in the form of anew user-friendly drop-down search function. Weight: 122

Name: Rear Anti Roll Bar Bush 21.7mmProduct Notes: Please check anti roll bar diameter before ordering Bush Size: 21.7mmWeight: 125

Name: Rear Anti Roll Bar Bush 21.7mmProduct Notes: Please check anti roll bar diameter before ordering Bush Size: 21.7mmWeight: 125

Name: Rear Diff Front Mounting BushProduct Notes: This bush fits models only where the bush location in the diff casing measures 30mm tall as found on AWD 2004-2015 PQ35 platform vehicles. If in doubt, measure the height of the front casing mount before ordering. If the mount is 35mm in height and the OEM part number on your vehicle is 1K0 599 437, please use PFR85-524. Bush Size: 30mmWeight: 415Fitting Instructions

Name: Rear Diff Front Mounting Bush Product Notes: This bush fits models only where the bush location in the diff casing measures 30mm tall as found on AWD 2004-2015 PQ35 platform vehicles. If in doubt, measure the height of the front casing mount before ordering. If the mount is 35mm in height and the OEM part number on your vehicle is 1K0 599 437, please use PFR85-524. Bush Size: 30mmWeight: 415Fitting Instructions

Name: Rear Diff Rear Mounting BushProduct Notes: Fits 4WD models only. Weight: 970Fitting Instructions

Name: Rear Diff Rear Mounting Bush Product Notes: This bush fits 4 wheel drive models only. Weight: 970Fitting Instructions

Name: Rear Lower Arm Inner Bush Product Notes: Weight: 663Fitting Instructions

Name: Rear Lower Arm Inner Bush Product Notes: Weight: 663Fitting Instructions

Name: Rear Lower Arm Outer Bush Product Notes: Weight: 412

Name: Rear Lower Arm Outer Bush Product Notes: Weight: 412

Name: Rear Lower Track Rod Inner BushProduct Notes: Weight: 542

Name: Rear Lower Track Rod Inner Bush Product Notes: Weight: 542

Name: Rear Lower Track Rod Outer Bush Product Notes: Weight: 495

Name: Rear Lower Track Rod Outer Bush Product Notes: Weight: 495

Name: Rear Subframe Front Mounting BushProduct Notes: This bush uses our Purple 80A durometer material with bonded supporting washers for strengthening and a bespoke end face design to reduce noise transmission to the cabin, whilst maintaining durability and subframe location. Weight: 1234Fitting Instructions

Name: Rear Subframe Front Mounting BushProduct Notes: This bush uses our Black 95A durometer material with bonded supporting washers for strengthening and a bespoke end face design to reduce noise transmission to the cabin, whilst maintaining durability and subframe location. Weight: 1234Fitting Instructions
